Beacon Solar Shelter / Canopy

Solar Shelter Canopy – Modular Rooftop Solar Power & Battery System

Categories: ,

Description

Data sheet

Brochure

The BEACON Solar Shelter / Canopy is a modular rooftop solar power and battery system designed to supply reliable off-grid energy under shelters and canopies. It provides dedicated power for lighting, CCTV, USB charging, and other low-voltage devices without the need for mains power supply or connection.

The system integrates high-efficiency 110Wp solar panels with scalable LiFePO4 battery storage options, allowing capacity to be matched to site requirements. A roof-mounted aluminium bracket system supports installation on flat or profiled metal roofing, making BEACON well suited to transport hubs, public shelters, and under canopy infrastructure applications.

Built with an IP66-rated housing, IP68 connectors, and corrosion-resistant aluminium construction, BEACON is engineered for long service life in exposed outdoor environments.

Technical

Product BEACON – Solar Shelter / Canopy
Overview Solar power and battery storage for under shelter lighting or other devices such as CCTV or USB charging
Solar Panel 110Wp
Panel Efficiency 22%
Battery Type LiFePO4 (12.8V)
Battery Capacity Options 36 Ah / 460.8 Wh (1 battery)
72 Ah / 921.6 Wh (2 batteries)
108 Ah / 1382.4 Wh (3 batteries)
Mounting Roof mounted using included bracket system
Typical Use / Application Rooftop / flat or profiled metal roofing
Material 6063-T5 aluminium alloy
Finish Black / Silver powder coat
IP Rating IP66 Unit housing / IP68 Connectors
IK Rating IK08
Operational Temperature Range -20 °C to +60 °C
Expected Lifetime 100,000 hours (L90 B10)
Certifications CE, FCC, UL8801, ANSI C136.31, ISO 9001
Warranty 6 + 10* years
Design Modular design
*Warranty period is listed as: Complete Unit + Battery (Pro-rata) | Full warranty details are available upon request at:
