SKYBASE-1000

CAT-V Solar Road / Highway Light

Categories: ,

Description

Data sheet

The SKYBASE-1000 Portable Solar Street Light has been developed for temporary roadway lighting applications where rapid deployment, reliability and compliance are critical.

Designed around a robust concrete block foundation system and hot-dipped galvanised steel pole, the system delivers infrastructure-grade lighting performance without the need for trenching, underground cabling or generator-powered lighting towers.

Available with up to 300W of LED roadway lighting output and up to 10.2kWh of LiFePO₄ battery storage, the SKYBASE-1000 can provide multiple nights of autonomy while maintaining all-night operation in demanding environments.

The system is suitable for temporary traffic management, road construction projects, detours, emergency response works, remote infrastructure projects and locations where conventional grid-powered lighting is impractical.

Key Features

  • Up to 300W LED roadway lighting output
  • Designed for AS1158 Category V roadway lighting applications
  • Available with 600W or 1000W solar array
  • Up to 10.2kWh LiFePO₄ battery storage
  • 4–10+ nights autonomy
  • Silent operation
  • No fuel consumption
  • No carbon emissions during operation
  • Hot-dipped galvanised steel pole construction
  • Vandal-resistant battery enclosure
  • IP66/IP68 protected electronics
  • Suitable for cyclone-prone regions
  • Rapid deployment without trenching or underground cabling

Technical

Part Number SKYBASE-1000
Lighting Specifications
Lighting Output 60W – 300W LED roadway lighting
Luminaire Sylvania ROADLED MIDI DC
Maximum Output Up to 300W (42,000 lumens)
Lighting Categories Designed for AS1158 Category V1, V2, V3, V4 and V5 applications
Mounting Options Single or twin outreach arms (3m–4m)
Solar Specifications
Solar Panel Options 600Wp or 1000Wp monocrystalline solar panels
Solar Efficiency 22%
Charging Method Solar charging
Battery Specifications
Battery Type LiFePO₄ with passive cell balancing
Battery Capacity 24V system with 4–6 battery configuration, up to 10,240Wh (10.2kWh)
Battery Life 2,000–6,000 cycles depending on operating conditions
Autonomy 4–10+ nights operation
Mechanical Specifications
Pole Height 9m–11.5m hot-dipped galvanised steel pole
Concrete Block Base 1.4m × 1.4m × 1.2m (custom designs available)
Security Vandal-resistant battery enclosure with key locks
Control & Connectivity
Control Options Optional Bluetooth module and handheld remote
Connectivity Optional DC output port for device charging
Remote Diagnostics Available
Environmental Specifications
Ingress Protection IP66 / IP68 controller and connectors
Impact Resistance IK08
Operating Temperature -20°C to 60°C
Application Environment Suitable for harsh and cyclone-prone regions
Certifications & Warranty
Certifications CE, FCC, ANSI C136.31, ISO9001
Warranty 5 year system warranty, 10 year limited battery warranty, 25 year limited solar panel warranty
